P Setting (Hold "+" and "-" to access) - Attention: Please note that any change to setting might affect the performance of the bike which could result in the bike stop moving, please do not change default setting unless you fully understand the system and know what can be changed (contact TN Ebike support team if have any questions)

P01: Backlight Brightness (1: darkest; 3:brightest)

P02: Mileage Unit (0: KM; 1: MILE)

P03: Voltage Class: 24V / 36V (default) / 48V

P04: Hibernation Time (0: never, other figures refer to the hibernation time) Unit: minute

P05: PAS Level -0/3 Gear Mode ; 1/5 Gear Mode

P06: Wheel Diameter- Unit:inch ; Precision: 0.1

*To get accurate speed display, this parameter should be correct.

P07: Magnet Steel Number for Speed Test Range: 1-100

*To get accurate speed display, this parameter should be correct.

Gearless Motor: the value is the magnet steel number.

Geared Motor: the reduction-gear ratio is required. The value = magnet steel number*reduction-gear ratio.

For example, magnet steel number is 20, reduction-gear ratio is 4.3. The value input is:86=20×4.3

P08: Speed Limit – Range:0-100km/h,parameter 100 indicates no speed limit. (Password to change speed is CODE: 8252 (for M5 display Black) and CODE: 8650 (for M5 Display white and CODE:1234 (small older display)

This parameter limits the max. speed of the vehicle. For example, input value 25 means the max. speed is 25km/h, the vehicle travelling speed can only reach the preset value.

Deviation: ±1km/h (applies to both PAS and throttle mode).

Note: The above-mentioned values are measured by metric unit (kilometers). When the measuring unit is switched to imperial unit (mile), the speed value displayed on the panel will be automatically switched to corresponding imperial unit, however the speed limit value in the imperial unit interface won’t change accordingly.

IMPORTANT: P09-P15 only works under communications mode.

P09: Zero / Non-zero Start Setting: 0: Zero Start1: Non-zero Start

P10: Drive Mode Setting

0: Power Drive – The specific gear of the assist drive decides the assist power value. In this status the handlebar does not work.

1:Electric Drive – The vehicle is driven by the handlebar. In this status the power gear does not work.

2: Power Drive +Electric Drive – Electric drive does not work in zero-start status.

P11: PAS Sensibility – Range:1-24

P12: Assist Power Intensity Range: 0-5

P13: Power Magnet Steel Number:5 / 8/ 12pcs

P14: Current Limit Value:12A by default; Range:1-20A

P15: Unspecified

P16: ODO Zero-Out: Long press the upper key for 5 seconds and ODO will zero out.
